Has the XY co-ordinates disappeared for your elaborate circuit design? Are you having trouble
navigating through the co-ordinate system representation in SOLIDWORKS Electrical? Here’s
the solution!
SOLIDWORKS Electrical Coordinate System
There are three modes for the Coordinates representation and these modes can be accessed by
clicking the Coordinates toggle option next to the grid icon in the status bar as shown below:
Another option to activate the toggle is on the left bottom corner of the status bar where the
status of the Coordinates, are represented as shown below:
The three modes of Coordinate System in SOLIDWORKS Electrical are:
The display of coordinates will not be shown in this mode. To activate and view the
This mode activates the coordinate system and shows instantaneous values of X & Y.
This mode represents the radian angle values at the specified points highlighted by theWith this Coordinates tool, your extensive designs are made easy to navigate, help you work
efficiently and effectively. Go on, It’s Time to Design with Precision!
